Gabler | Thermoforming | Roll automatons for forming and punching

Gabler M92L

Year: 2006
Available

Technical Specifications

Ref. NoTF-12
BrandGabler
SubcategoryRoll automatons for forming and punching
ConditionVery good Condition
Hours72000
DeliveryImmediately

Description

Thermoforming machine with:

  • Pre-heater
  • Stacking unit

- Forming area 750 x 436 mm

- Film width for PP 410...804 mm

- Film width for PS 410...814 mm

- Drawing depth negative 150 mm (standard) 200 mm (optional)

- Power upper heating 81,90 kW

- Power bottom heating 54,60 kW

- Mains voltage 400V AC

- Frequency 50 Hz

- Voltage for consumer 230 V AC 24 V DC

- Control voltage 24 V DC

- Total connected load approx. 138.66 kW

- Punching force max. 350 KN

-load cycles 44 cycles/minute

‍

‍

×
