ILLIG (Special) Equipment for the Forming Station

Pre-stretch Punch Variants:
010749

  • Servo-driven pre-stretch punch, 150 mm draw depth, with central lubrication

Form Air Supply Variants:
011846

  • Form air supply through the mounting bars

015113

  • Form station with column length for the use of 3rd generation forming tools (tool block size 770 mm): 2nd generation tools can be used with an adapter.

30/100 010751

  • Pneumatic stripper plate lift and additional stripper plate pressure stage (pre-cooling and punching pressure)

30/110 011911

  • Additional pump for ejector and, if applicable, stripper plate with direct connection to the customer’s central cooling system or cooling unit, along with additional flow rate indicators for upper and lower tools

Machine includes a ILLIG VHW 90/2 , ILLIG RS75b Grinder, Deflection device for guiding the film to the grinder and a ILLIG Stacking station SZS73.

Maximum Forming Area – 680 x 280 mm

Maximum Forming Height – 150 mm

Maximum Film Width – 730 mm

Maximum Feed Length – 300 mm

Maximum Clamping Force – 25.000 daN

Maximum Cutting Length – 5.000 mm

Idle Speed – 35 min⁻¹

Electrical Connection Power for Top and Bottom Heaters – 74,2 kW

Electrical Connection Power for Motors – 8.43 kW

Total Electrical Connection Power with Top and Bottom Heaters – 82,7 kW

Compressed Air Requirement per Cycle at 6 bar/min (Basic Machine) – 230 L

Compressed Air Requirement per Cycle at 6 bar/min (with Hydraulic Upper Platen) – 180 L

Machine Length with Film Roll, Stacking, Counting, and Ejector Unit – 7.300 mm

Machine Width without Control Cabinet (with Hydraulic Unit) – 2.760 mm

Total Height (Basic Machine) – 2.700 – 3.400 mm

Total Weight – 80.200 kg

In Store

ILLIG RDM 70K

ILLIG

Automatic roll-fed for forming/punching

2012
year of manufacture

Very good Condition

In Production
34528
hours
Immediately
